Clevises with Rotating Shaft

Have same dimensions like DIN71752, but the Clevises with Rotating Shaft are rotatable, so there is no need to adjust the radial position when mounting. The totating shaft will compensate radial movements cased by axes or levers which are not accurately in lone or by bowden cable. When mounting, all movable parts and contact surfaces should be lubricated.

Send Inquiry

Product Description

Part No.	Dimensions										Static load	Weight
	a	b	d₁	d₂	d₃	l₁	l₂	l₃	l₄	sw
FKR 4X8	8	4	4	M4	8	8	16	21	3. 0	6	500	0. 006
FKR 4X16	8	4	4	M4	8	16	24	29	3. 0	6	500	0. 008
FKR 5X10	10	5	5	M5	9	10	20	26	4. 0	7	800	0. 010
FKR 5X20	10	5	5	M5	9	20	30	36	4. 0	7	800	0. 014
FKR 6X12	12	6	6	M6	10	12	24	31	5. 5	9	2400	0. 016
FKR 6X24	12	6	6	M6	10	24	36	43	5. 5	9	2400	0. 023
FKR 8X16	16	8	8	M8	14	16	32	42	8. 0	12	3400	0. 038
FKR 8X32	16	8	8	M8	14	32	48	58	8. 0	12	3400	0. 055
FKR 10X20	20	10	10	M10	18	20	40	52	11. 5	16	6000	0. 080
FKR 10X40	20	10	10	M10	18	40	60	72	11. 5	16	6000	0. 120
FKR 12X24	24	12	12	M12	20	24	48	62	14. 0	18	14000	0. 125
FKR 12X48	24	12	12	M12	20	48	72	86	14. 0	18	14000	0. 180
FKR 14X28	27	14	14	M14	24	28	56	72	18. 5	22	16000	0. 190
FKR 14X56	27	14	14	M14	24	56	85	101	18. 5	22	16000	0. 265
FKR 16X32	32	16	16	M16	26	32	64	83	20. 0	24	18000	0. 300
FKR 16X64	32	16	16	M16	26	64	96	115	20. 0	24	18000	0. 430

Code of thread: fine-pitch thread – FG, left-handed thread – LH, fine-pitch and left-handed thread-FGLH.

Material and surface treatments:

Fork: low carbon steel Q235A; Coated with rust-proof oil, zinc plating or nickel plating.

Shaft: medium carbon steel 45; Coated with rust-proof oil, zinc plating or nickel plating.

Ring: spring steel; Coated with rust-proof oil, zinc plating or nickel plating.

Ningbo Dongzhou Transmission Co., ltd is Well equipped with more than 300 all kinds of precision machining equipments and professional testing instruments. Ningbo Dongzhou Transmission Co., ltd is leading manufacturer of Clevises with Rotating Shaft and Clevises with Rotating Shaft suppliers which specialized in manufacturing mechanical spare parts, farm machinery parts and auto parts like Clevises, Bolts, Clips, Rod Ends, Radial Spherical Plain Bearing, Ball Joints and so on. Non-standard products can be designed and put into production as per samples or drawings accordingly. Factory manufactured Clevises with Rotating Shaft are well welcomed both at home and abroad markets like USA, Europe, Middle East, Southeast Asia, etc. We also wholesale these products worldwide.
